Rigol MSO5000 Series Mixed Signal Oscilloscopes
Bandwidth: 70MHz, 100MHz, 150MHz, 200MHz, 350MHz | Channels: 2/4 + 16 (Opt) | Max Sample Rate: 4GSa/s,8GSa/s
- Bode Plot: Switching Power Supply Loop Analysis
- 7 in 1 Product Design
- 9 “multi Touch Capacitive Screen
- Convenient Web Control Remote Control
- Support Up to 450000 Frames of Hardware Waveform Recording Analysis
- Waveform Capture Rate Up to 500,000 Times Per Second
- Super High Sampling Bandwidth Ratio
- Full Memory Hardware Measurement
The MSO5000 Series Oscilloscopes combine best in class sampling and memory depth with our modern, flexible User Interface enabled by our new UltraVision II architecture and innovative Phoenix Chipset. With 70 to 350MHz models each with 2 or 4 channels, the MSO5000 Series brings innovative flexibility and capability to the engineer’s bench. Analyse your critical signals with zone triggering, 7 instruments in 1, Enhanced FFT’s, colour grading, and histograms all supported by the high sample rate, deep memory and full memory measurements.
| Model | Channels | Bandwidth | Max Sample Rate | Memory | Signal Generator | Waveform Refresh Rate | Price |
|---|---|---|---|---|---|---|---|
| MSO5072 | 2 + 16 Digital (Opt) | 70MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfms/s | £729.00 |
| MSO5074 | 4 + 16 Digital (Opt) | 70MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfms/s | £713.00 |
| MSO5102 | 2 + 16 Digital (Opt) | 100MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfms/s | £ £812.00 |
| MSO5104 | 4 + 16 Digital (Opt) | 100MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfms/s | £ £856.00 |
| MSO5152-E | 2 + 16 Digital (Opt) | 150MHz | 4GSa/s | 100Mpts – Standard | X1 (Opt) | 300,000 wfms/s | £810.00 |
| MSO5204 | 4 + 16 Digital (Opt) | 200MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfms/s | £1,365.00 |
| MSO5354 | 4 + 16 Digital (Opt) | 350MHz | 8GSa/s | 100Mpts – Standard 200Mpts – Optional | X2 (Opt) | 500,000 wfms/s | £1821.00 |
