DC Electronic Loads
| Model | Total Power | Maximum Current | Display | Max. Current Slew Rate | Max. Continuous Mode Frequency | Readback Current Resolution | Digital I/O | Communications Interfaces | Price |
|---|---|---|---|---|---|---|---|---|---|
| DL3021 | 200W | 40A | Limited Colour | 2.5A/μs (std.) 3.0A/μs (opt.) | 15kHz (std.) 30kHz (opt.) | 1mA (std.) 0.1mA (opt.) | Optional | USB Device, USB Host & RS232 – Standard LAN & GPIB – Optional | £395.00 |
| DL3021A | 200W | 40A | Full Colour | 3.0A/μs | 30kHz | 0.1mA | Standard | USB Device, USB Host, LAN & RS232 – Standard GPIB – Optional | £ £547.00 |
| DL3031 | 350W | 60A | Limited Colour | 2.5A/μs (std.) 5.0A/μs (opt.) | 15kHz (std.) 30kHz (opt.) | 1mA (std.) 0.1mA (opt.) | Optional | USB Device, USB Host & RS232 – Standard LAN & GPIB – Optional | £864.00 |
| DL3031A | 350W | 60A | Full Colour | 5.0A/μs | 30kHz | 0.1mA | Standard | USB Device, USB Host, LAN & RS232 – Standard GPIB – Optional | £ £1,030.00 |
| Model | Total Power | Maximum Current | Display | Max. Current Slew Rate | Max. Continuous Mode Frequency | Readback Current Resolution | Digital I/O | Communications Interfaces | Price |
|---|---|---|---|---|---|---|---|---|---|
| DL3021 | 200W | 40A | Limited Colour | 2.5A/μs (std.) 3.0A/μs (opt.) | 15kHz (std.) 30kHz (opt.) | 1mA (std.) 0.1mA (opt.) | Optional | USB Device, USB Host & RS232 – Standard LAN & GPIB – Optional | £395.00 |
| DL3021A | 200W | 40A | Full Colour | 3.0A/μs | 30kHz | 0.1mA | Standard | USB Device, USB Host, LAN & RS232 – Standard GPIB – Optional | £ £547.00 |
| DL3031 | 350W | 60A | Limited Colour | 2.5A/μs (std.) 5.0A/μs (opt.) | 15kHz (std.) 30kHz (opt.) | 1mA (std.) 0.1mA (opt.) | Optional | USB Device, USB Host & RS232 – Standard LAN & GPIB – Optional | £864.00 |
| DL3031A | 350W | 60A | Full Colour | 5.0A/μs | 30kHz | 0.1mA | Standard | USB Device, USB Host, LAN & RS232 – Standard GPIB – Optional | £ £1,030.00 |
