Description
Features:
- Bandwidth: >2.5GHz
- Rise Time: <140ps
- System Bandwidth: 2.5GHz
- Input Capacitance: <1pF
- Input Resistance: 50kΩ±2% Differential, 25kΩ±4% Single-Ended
- Input Dynamic Range: ±2V
- Input Common Mode Range: ±6.25V DC to 100Hz, ±1.25V >100Hz
- Common Mode Rejection Ratio: >45dB@1MHz
- DC Attenuation: 10:1 ±2%
- Zero Offset Error: <30mV Before Calibration, <5mV After Calibration
- Offset Voltage Range: ±2V
- Offset Accuracy: <3% of current range before calibration, <1% of current range after calibration
- Input Noise: 3.8mVpp
- Propagation Delay: 7ns
- Max Input Voltage: 30V Peak CAT I
- Electrostatic Protection (HBM): >8kV
