Description
Features:
- Bandwidth: 100MHz (-3 dB)
- Rise Time: ≤3.5ns
- Accuracy: ±2%
- Range (Attenuation): 50X/500X
- Maximum Measurable Differential Voltage (DC + peak AC): 50X: ±150V, 500X: ±1500V
- Common Mode Voltage (DC + peak AC): ±1500V
- Maximum Input Voltage-to-Earth (Vrms): 600V CAT III, 1000V CAT II
- Input Impedance: Between each input and ground; 5MΩ±1%. Between differential inputs; 10MΩ±1%
- Input Capacitance: Between each input and ground; <4pF. Between differential inputs; <2pF
- CMRR: DC; >80dB. 100kHz; >60dB. 1MHz; >50dB. 3.2MHz; >30dB. 50MHz; >26dB.
- Input Referred Noise (Vrms): 50X; <50mV. 500X; <300mV.
- Delay: 16ns
- Bandwidth Limit (5MHz): ≥-3dB@5MHz
- Output Impedance: 50Ω
