Rigol DP832A Linear DC Power Supply (30V/3A & 30V/3A & 5V/3A)
Rigol DP832A Linear DC Power Supply (30V/3A & 30V/3A & 5V/3A)

Rigol DP832A Linear DC Power Supply (30V/3A & 30V/3A & 5V/3A)

£507.00 (£608.40 inc VAT)

Available on back-order, delivery normally 1 - 2 weeks

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

SKU: DP832A Categories: , Brand:

Description


Product Images

Product Videos

YouTube Video
YouTube Video
YouTube Video

Documentation

User Guide

Rigol DP800 User Guide



Datasheet

Rigol DP800 Datasheet



Specifications

Rigol DP800 Specifications



Application Notes

Converting DP800 Record *ROF Files

Active loads and the DP800, DP1000 series of Power Supplies

Debug and Analysis of IoT Power Requirements



DC Output (0°C to 40°C)
ModelDP811ADP821ADP831ADP832A
Voltage/Current RatingRange 1: 0 to 20V/0 to 10A
Range 2: 0 to 40V/0 to 5A		CH1: 0 to 60V/0 to 1A
CH2: 0 to 8V/0 to 10A		CH1: 0 to 8V/0 to 5A
CH2: 0 to 30V/0 to 2A
CH3: 0 to -30V/0 to 2A		CH1: 0 to 30V/0 to 3A
CH2: 0 to 30V/0 to 3A
CH3: 0 to 5V/0 to 3A
OVP/OCPRange 1: 1mV to 22V/0.1mA to 11A
Range 2: 1mV to 44V/0.1mA to 5.5A		CH1: 1mV to 66V/0.1mA to 1.1A
CH2: 1mV to 8.8V/1mA to 11A		CH1: 1mV to 8.8V/0.1mA to 5.5A
CH2: 1mV to 33V/0.1mA to 2.2A
CH3: -1mV to -33V/0.1mA to 2.2A		CH1: 1mV to 33V/1mA to 3.3A
CH2: 1mV to 33V/1mA to 3.3A
CH3: 1mV to 5.5V/1mA to 3.3A
Load Regulation Rate ± (Output Percentage + Offset)
Voltage<0.01% + 2mV<0.01% + 2mV<0.01% + 2mV<0.01% + 2mV
Current<0.01% + 250μA<0.01% + 250μA<0.01% + 250μA<0.01% + 250μA
Linear Regulation Rate ± (Output Percentage + Offset)
Voltage<0.01% + 2mV<0.01% + 2mV<0.01% + 2mV<0.01% + 2mV
Current<0.01% + 250μA<0.01% + 250μA<0.01% + 250μA<0.01% + 250μA
Ripples and Noise (20Hz to 20MHz)
VoltageDP832A/DP831A/DP821A: <350μVrms/2mVpp
DP811A: <350μVrms/3mVpp		DP832A/DP831A/DP821A: <350μVrms/2mVpp
DP811A: <350μVrms/3mVpp		DP832A/DP831A/DP821A: <350μVrms/2mVpp
DP811A: <350μVrms/3mVpp		DP832A/DP831A/DP821A: <350μVrms/2mVpp
DP811A: <350μVrms/3mVpp
Current<2mArms<2mArms<2mArms<2mArms
Transient Response Time
Transient Response TimeLess than 50μs for output voltage to recover to within 15mV following a change in output current from full load to half load or vice
versa.		Less than 50μs for output voltage to recover to within 15mV following a change in output current from full load to half load or vice
versa.		Less than 50μs for output voltage to recover to within 15mV following a change in output current from full load to half load or vice
versa.		Less than 50μs for output voltage to recover to within 15mV following a change in output current from full load to half load or vice
versa.
Command Processing Time
Command Processing Time<118ms<118ms<118ms<118ms

Note* Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.

Reviews

  1. Steve C –

    Great PSU – Excellent dealer service
    I have wanted the Rigol DP832A for quite some time but was concerned at the inadequate cooling in the early models of the LM317 voltage regulator. Knowing that the revised boards were now coming on stream I decided to take the plunge and was more than surprised and impressed with the help offered by Telonic systems who were totally up front about the issues and were more than happy to help me get exactly the machine I wanted with the revised board and also the larger heatsink. First rate service – sincere thanks!

    The PSU is an excellent piece of equipment – performs very well, does not suffer from undue noise and the output settings are absolutely correct as measured with my accurate Agilent 34461A. I find the user interface easy to work with and the info on the LCD screen very helpful. Well built equipment that will be a pleasure to use for years to come I am sure.
